Steel-Core Swab Cup Catalogue: 4-1/2, 5-1/2 and 7-Inch References

Royal Way supplies steel-core swab cup enquiries for equipment-defined well servicing. This page retains a catalogue table for 4-1/2, 5-1/2 and 7-inch nominal references. Confirm the exact cup profile, actual diameters and mandrel fit. Review NBR or FKM grades for the fluid and temperatures; a cup has no independent 10,000 psi pressure rating.

The existing TA, V and MV references describe different cup profiles and support arrangements. Select the required profile by the tool drawing and operating duty. Do not apply one load or pressure claim to every design or infer interchangeability from a nominal size.

The original size table below lists steel-core cup OD, ID and weight references for 4-1/2, 5-1/2 and 7-inch nominal sizes. Specify the selected catalogue dimensions, core material and measurement basis on the approved drawing. Custom enquiries require agreed tolerances and inspection criteria.

Larger Steel-Core Swab Cups: Confirm Dimensions and Weight Basis

The retained 4-1/2-inch row lists OD 4.062 in / 103.17 mm and ID 2.420 in / 61.47 mm. The 5-1/2 and 7-inch rows have separate dimensions. Identify the intended row and tool profile rather than using the nominal size as the rubber diameter.

The old weight column is retained for reference, but confirm whether it describes the complete cup or another component before using it for shipping or engineering calculations. Provide core bore, cup height, profile drawing, compound and permitted tool duty with the order.

Replacement cup enquiries can be discussed from the required profile and approved drawing. Specify the nitrile or other compound grade and actual fluid exposure. Profile references do not imply original-brand manufacture or universal compatibility.
